Rhodan Gen5 GPS Trolling Motor — 36V | 48" Shaft | White
The Rhodan Gen5 48" White (36V) is built for heavier offshore boats with a low bow height under 30" — delivering 120 lbs of thrust to hold position in the demanding conditions that define offshore saltwater fishing: rough inlets, tidal current, open bays, and nearshore structure. It carries the same GPS Anchor dynamic positioning system, full-screen base display, and native Simrad, Raymarine, and Lowrance integration as every Gen5 motor, with the added power of 36V for boats that need it.
The white finish is particularly popular on offshore center consoles and bay boats with white gelcoat, blending cleanly with modern saltwater boat styling while delivering the same proven Gen5 offshore performance.
Available Finishes: ⚫ Black | ⚪ White (Current Model)
Manufactured in Sarasota, Florida with 90% U.S. content. Backed by a 5-year limited warranty with direct access to Rhodan's customer service team.
Is This the Right Model for Your Boat?
| Choose this model if... | Consider another model if... |
|---|---|
| You need maximum 36V thrust on a lower-bow offshore or heavy bay boat | Your bow height requires a 60", 72", or longer shaft |
| You fish strong tidal current, rough inlets, or offshore structure | A 24V system adequately serves your boat and fishing conditions |
| Your vessel weighs 6,000–15,000 lbs with a bow height under 30" | You run Garmin electronics and want native helm integration |
Why Choose 36V Instead of 24V?
The 36V Gen5 produces 120 lbs of thrust — 50% more than the 24V. That difference is not about speed. It's about holding power under load, steering authority in wind, and runtime when the motor is working hard.
Choose the 36V Rhodan Gen5 if you:
- Regularly fish in strong tidal current — inlets, passes, bridge pilings, and tidal flats
- Own a heavier bay boat or center console over 6,000 lbs
- Fish offshore reefs, wrecks, and live bottom where GPS Anchor hold is critical
- Need maximum steering authority in wind and chop
- Carry multiple anglers and heavy gear that pushes your vessel weight up
- Want additional thrust reserves rather than operating near maximum output
- Fish in conditions where a 24V motor would be working at or near its limit
If your boat is under approximately 6,000 lbs and you primarily fish protected bays, flats, or inshore waters, the 24V Rhodan Gen5 may be a better fit — and a lower-cost one.
Why Choose the 36V 48" Model?
The 48" shaft is the shortest in the Gen5 36V lineup — and that makes it intentional, not incidental. This model is ideal if you need:
- Maximum 36V thrust — 120 lbs of holding power for heavier offshore vessels
- But your boat's bow height does not require a longer shaft — your bow sits under 30" with a typical fishing load
- The lightest, most maneuverable option in the 36V lineup — shorter shaft means less leverage and weight at the bow
Most offshore center consoles will need a longer shaft — the 48" is the exception in the 36V lineup, not the rule. It's the right motor for a specific and uncommon boat profile: heavy enough to need 36V, but with a bow that sits low enough that a 48" shaft is the correct fit.
If your bow height is at or near 30", step up to the 60" shaft. Offshore conditions are less forgiving than inshore — a prop that breaks the surface in chop loses all thrust instantly.
Who Should Choose the Rhodan Gen5 36V 48" Shaft?
This motor is ideal for:
- Offshore center consoles and deep-V hulls between 6,000 and 15,000 lbs with a bow height under 30"
- Anglers fishing rough inlets, tidal passes, nearshore reefs, and offshore wrecks
- Boats that need sustained GPS Anchor hold in wind and current
- Anglers running Simrad, Raymarine, or Lowrance electronics
Excellent for these species and scenarios:
- Snapper · Grouper · Cobia · Amberjack · Tarpon · King Mackerel · Mahi
- Nearshore reef and wreck fishing
- Offshore structure and ledge fishing
- Bridge and inlet fishing in strong tidal current
- Anchoring over live bottom in wind and chop
- Extended offshore trips requiring all-day runtime
Who Should NOT Buy This Motor
Don't buy this model if:
- Your bow height is at or above 30" — step up to the 36V 60" shaft
- Your vessel weighs under 6,000 lbs — the 24V 48" White is the correct and more cost-effective choice
- You primarily fish freshwater lakes or protected inshore waters where 24V is sufficient
- You run Garmin electronics and want native helm integration — the Garmin Force Kraken is the correct motor
We'd rather help you find the right motor than sell you the wrong one. Contact TrollingMotors.shop if you're unsure.
Real-World Performance — Where This Motor Works
The 36V Gen5 is built for the conditions where GPS Anchor hold is hardest to maintain and most critical to have. On a 36V system, GPS Anchor has more thrust reserve to draw from when conditions deteriorate — meaning more consistent hold through tidal current changes, wind shifts, and the kind of chop that pushes lighter motors off position.
Offshore wrecks and artificial reefs: Hold position precisely over structure in tidal flow and wind. The 36V system maintains GPS Anchor hold when conditions build during the day — keeping you on target when current is running hard.
Bridge pilings in tidal current: Fish tidal current edges and bridge shadow lines without constant repositioning. GPS Anchor holds through current changes, letting you focus on the fish instead of the motor.
Nearshore reefs and live bottom: Stay over structure in wind and current without re-anchoring. The additional thrust reserve keeps you locked on target when conditions deteriorate.
Inlet edges in changing wind: Maintain station in the chop and current that builds in inlet mouths. The 36V system has the thrust to hold where a 24V motor would struggle — especially when wind and current are working against each other.
Offshore structure and ledges: Work ledges and bottom transitions in open water where wind and current combine. Extended runtime under load keeps you fishing longer without worrying about battery reserves.
Extended offshore trips: All-day runtime under demanding conditions. The 36V system operates with more thrust reserve, drawing less proportional current at typical fishing speeds.
Typical Boats for the 36V 48" Shaft
The following are representative examples of heavier offshore boats with a low bow profile that commonly pair with a 36V 48" shaft. This is not a compatibility guarantee — always confirm your specific bow height and vessel weight before ordering.
- Contender 25 Bay (heavier configurations)
- Yellowfin 24 Bay (heavier rigged configurations)
- Robalo R242 (heavier configurations)
- Pursuit S 268 (low-bow configurations)
Shaft Selection at a Glance — 36V Series
| Shaft | Best Bow Height | Typical Boat | Best For |
|---|---|---|---|
| 48" ← This motor | Under 30" | Low-bow offshore center consoles | Maximum thrust, lightest 36V option |
| 60" | 30–36" | Heavier bay boats, moderate offshore | Most common 36V inshore/nearshore fit |
| 72" | 36–42" | Large bay boats, higher bows | Higher-bow offshore center consoles |
| 84" | 42–48" | Offshore center consoles | Standard offshore CC fit |
| 96" | 48–54" | High-freeboard offshore boats | High-bow offshore center consoles |
| 108" | 54–60" | Large offshore / charter boats | Tournament and charter applications |
| 120" | 60"+ | Extreme offshore / maximum freeboard | Largest offshore applications |
When in doubt, choose the next longer shaft. Offshore conditions are less forgiving than inshore — a prop that breaks the surface in chop loses all thrust instantly. → Use Rhodan's official size guide to confirm your selection.
24V vs. 36V — Which Is Right for Your Boat?
| Factor | 24V | 36V (this motor) |
|---|---|---|
| Thrust | 80 lbs | 120 lbs |
| Vessel weight | Under 6,000 lbs | 6,000–15,000 lbs |
| Typical boat | Flats boats, bay boats | Offshore center consoles, deep-V hulls |
| Typical conditions | Moderate wind and current | Rough inlets, tidal passes, offshore structure |
| Runtime under load | Good for inshore use | Extended runtime in demanding conditions |
| Steering authority | Sufficient for lighter vessels | Maximum authority in wind and chop |
GPS Anchor — Rhodan's Precision Dynamic Positioning System
Rhodan's GPS Anchor uses a dynamic positioning system that continuously calculates and applies thrust corrections to hold your exact GPS position — compensating for wind, current, and wave action in real time. On a 36V system, GPS Anchor has more thrust reserve to draw from when conditions deteriorate.
Activate from the wireless FOB remote, the Rhodan app, or directly from the base display.
Simrad, Raymarine & Lowrance Integration
The Gen5 supports native integration with compatible Simrad, Raymarine, and Lowrance multifunction displays through Rhodan's supported NMEA 2000 networking and gateway hardware — the Rhodan MFD Gateway and a properly configured NMEA 2000 network.
Important: Integration requires the Rhodan MFD Gateway, a compatible NMEA 2000 backbone, T-connector, and compatible display firmware. Confirm display compatibility and required networking hardware with Rhodan or TrollingMotors.shop before purchase.
If you run Garmin, the Garmin Force Kraken is the correct motor for native Garmin integration.
Key Specifications
- Model: G5W36048
- Shaft length: 48"
- Finish: White
- Voltage: 36V
- Thrust: 120 lbs
- Recommended vessel weight: 6,000–15,000 lbs
- Recommended bow height: Under 30"
- GPS system: GPS Anchor (dynamic positioning)
- MFD integration: Simrad, Raymarine, Lowrance (via MFD Gateway + NMEA 2000)
- Base display: Full-screen with button controls
- Sliding base: 10" front-to-back adjustment
- Warranty: 5-year limited
- Origin: Made in Sarasota, Florida (90% U.S. content)
- Includes: Wireless FOB remote, Quick Release Bracket, RAM Mount Stabilizer
- Required: Properly rated marine circuit breaker — do not use SKU A00155
Before You Order — Checklist
- ☐ Bow height under 30" (mounting surface to waterline with fishing load)
- ☐ Vessel weight 6,000–15,000 lbs
- ☐ 36V battery system available or planned
- ☐ Adequate bow clearance for 48" shaft
- ☐ If using MFD integration: NMEA 2000 backbone and display compatibility confirmed
Not sure? Contact TrollingMotors.shop before ordering.
Explore the Full Rhodan Gen5 36V Lineup
36V (120 lbs thrust — boats 6,000–15,000 lbs):
- 48" | Black | 48" | White (this product) — Maximum thrust, lightest 36V option
- 60" | Black | 60" | White — Heavier bay boats and moderate offshore
- 72" | Black | 72" | White — Large bay boats and higher bows
- 84" | Black | 84" | White — Offshore center consoles
- 96" | Black | 96" | White — High-freeboard offshore boats
- 108" | Black | 108" | White — Charter and tournament boats
- 120" | Black | 120" | White — Extreme offshore applications
Also available in 24V (80 lbs thrust — boats under 6,000 lbs): 48" | Black | 48" | White
Why Buy From TrollingMotors.shop?
- ✓ Authorized Rhodan Marine Systems Dealer
- ✓ Free Nationwide Shipping
- ✓ Expert Technical Support — before and after your purchase
- ✓ Battery & Circuit Breaker Guidance
- ✓ MFD Integration Support
- ✓ Genuine OEM Product — factory warranty intact
Made & Supported in the USA
Every Rhodan Gen5 is manufactured in Sarasota, Florida using U.S. and globally sourced parts (90% U.S. content). When you call Rhodan Marine Systems, you reach their customer service team in Florida — not an overseas call center.
Rhodan Gen5 vs. Garmin Force Kraken
- Rhodan Gen5 — native Simrad, Raymarine, and Lowrance integration via MFD Gateway. Proven GPS Anchor heritage. Made in the USA.
- Garmin Force Kraken — native Garmin chartplotter integration. Brushless motor. The correct choice for anglers running Garmin electronics.
→ Full comparison: Garmin Force Kraken vs. Rhodan Gen5
Frequently Asked Questions
Why do I need 36V instead of 24V?
If your vessel weighs over 6,000 lbs, or you regularly fish in strong tidal current, rough inlets, or offshore structure, 24V (80 lbs thrust) may not provide sufficient holding power. The 36V system produces 120 lbs of thrust — 50% more — with greater steering authority in wind and longer runtime under demanding conditions.
Why choose the 48" shaft on a 36V motor?
The 48" is the lightest, most maneuverable option in the 36V lineup — correct when you need maximum 36V thrust but your bow height is under 30" and doesn't require a longer shaft. If your bow height is at or near 30", step up to the 60" shaft.
Does the Gen5 work with Garmin chartplotters?
No — the Gen5 integrates natively with Simrad, Raymarine, and Lowrance via Rhodan's MFD Gateway and NMEA 2000. For Garmin integration, the Garmin Force Kraken is the correct motor.
Is a circuit breaker required?
Yes. Confirm the correct breaker SKU with Rhodan or TrollingMotors.shop before purchasing — do not use SKU A00155, which Rhodan identifies as a Legacy breaker not compatible with the Gen5.
What battery system does the 36V Gen5 require?
Three 12V marine batteries wired in series, or a dedicated 36V lithium battery. Confirm battery capacity with TrollingMotors.shop for your runtime requirements.
Where is the Rhodan Gen5 made?
Sarasota, Florida, using U.S. and globally sourced parts (90% U.S. content).
What warranty does the Gen5 include?
A 5-year limited warranty with direct access to Rhodan's customer service department.
Does the remote come included?
Yes. The Gen5 includes a wireless FOB remote, a Quick Release Bracket, and a RAM Mount Stabilizer.
